C01352
Bit 6 NetRef Reference speed/reference torque:
0 ≡ via local setting in the device or terminal
1 ≡ via fieldbus (e.g. by the scanner)
Bit 7 Reserved
Bit 8 Reserved
Bit 9 Reserved
Bit 10 Reserved
Bit 11 Reserved
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Reserved
Bit 15 Reserved
Subcodes Info
C01351/1 ACDrive: Control word
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C01351 | ACDrive: Control word
Data type: UNSIGNED_16
Index: 23224
d
= 5AB8
h
Parameter | Name:
C01352 | ACDrive: Status word
Data type: UNSIGNED_16
Index: 23223
d
= 5AB7
h
From version 13.00.00
Display of the "AC Drive Profile" status word of the inverter
• Detailed information on the "AC Drive Profile" can be found in the EtherNet/IP™ communication manual.
Actuating drive speed (AC Drive Profile)
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 Faulted 0 ≡ No errors
1 ≡ Errors have occurred
Bit 1 Warning 0 ≡ No warnings
1 ≡ Warnings have occurred
Bit 2 Running1 (Fwd) Relationships between Run1 and Run2 and trigger
events can be found in the chapter "Run/Stop Event
".
Bit 3 Running2 (Rev)
Bit 4 Ready 0 ≡ Different status than in case of "1"
1 ≡ Ready or Enabled or Stopping
Bit 5 Ctrl from Net Run/Stop control:
0 ≡ via local setting in the device or terminal
1 ≡ via fieldbus (e.g. by the scanner)
Bit 6 Ref from Net Reference speed/reference torque:
0 ≡ via local setting in the device or terminal
1 ≡ via fieldbus (e.g. by the scanner)
Bit 7 At Reference 1 ≡ Currently, the inverter runs with the reference speed
or reference torque (depending on the "drive mode" set
in C01350/1
).
