15 Parameter reference
15.2 Parameter list
1096
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01353
C01469
C01470
Bit 8 DriveState_0 The "Drive State" is coded as follows:
0: Manufacturer-specific (not used with 8400)
1: Start-up (drive initialisation)
2: Not_Ready (mains voltage switched off)
3: Ready (mains voltage switched-on)
4: Enabled (drive has received "Run" command)
5: Stopping (drive has received "Stop" command and is
stopped)
6: Fault_Stop (drive is stopped due to an error)
7: Faulted (errors have occurred)
Bit 9 DriveState_1
Bit 10 DriveState_2
Bit 11 DriveState_3
Bit 12 DriveState_4
Bit 13 DriveState_5
Bit 14 DriveState_6
Bit 15 DriveState_7
Subcodes Info
C01352/1 ACDrive: Status word
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C01352 | ACDrive: Status word
Data type: UNSIGNED_16
Index: 23223
d
= 5AB7
h
Parameter | Name:
C01353 | ACDrive: Setpoint scaling
Data type: INTEGER_8
Index: 23222
d
= 5AB6
h
From version 13.00.00
Actuating drive speed (AC Drive Profil): Scaling of the speed and torque values
Setting range (min. value | unit | max. value)
-128 127
Subcodes Lenze setting Info
C01353/1 0 ACDrive: Speed scaling
C01353/2 0 ACDrive: Torque scaling
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01469 | L_MFail: Vp
Data type: UNSIGNED_16
Index: 23106
d
= 5A42
h
Setting range (min. value | unit | max. value)
0.001 31.000
Subcodes Lenze setting Info
C01469/1 1.000 L_MFail_1
: Vp
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C01470 | L_MFail: Tn
Data type: UNSIGNED_16
Index: 23105
d
= 5A41
h
Setting range (min. value | unit | max. value)
0 ms 60000
Subcodes Lenze setting Info
C01470/1 20 ms L_MFail_1
: U DC-bus controller reset time
C01470/2 20 ms L_MFail_1
: Acceleration time
C01470/3 20 ms L_MFail_1
: Retrigger time
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
