Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1097
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01501
C01670
Parameter | Name:
C01501 | Resp. to communication error with MCI
Data type: UNSIGNED_8
Index: 23074
d
= 5A22
h
Configuration of monitoring functions for the communication module
Selection list
0 No Reaction
1Fault
2Trouble
3 TroubleQuickStop
4 WarningLocked
5 Warning
6 Information
Subcodes Lenze setting Info
C01501/1 0: No Reaction Resp. to MCI connection error
• Response to a communication error of the attached
communication module.
C01501/2 0: No Reaction Resp. to MCI invalid module
• Response to an unplugged or incompatible
communication module
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01670 | L_ComparePhi 1-5: Function
Data type: UNSIGNED_8
Index: 22905
d
= 5979
h
Selection of comparison operation
• If the statement of the selected comparison operation is true, the binary bOut output will be set to TRUE.
Selection list
1In1 = In2
2In1 > In2
3In1 < In2
4 |In1| = |In2|
5 |In1| > |In2|
6 |In1| < |In2|
Subcodes Lenze setting Info
C01670/1 1: In1 = In2 L_ComparePhi_1
: Function
C01670/2 1: In1 = In2 L_ComparePhi_2
: Function
C01670/3 1: In1 = In2 L_ComparePhi_3
: Function
C01670/4 1: In1 = In2 L_ComparePhi_4
: Function
C01670/5 1: In1 = In2 L_ComparePhi_5
: Function
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
