Lenze 8400 - Page 1103

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1103
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01903
C01905
C02200
Selection list (Lenze setting printed in bold)
192 19.200 Bd
384 38.400 Bd
576 57.600 Bd
750 75.000 Bd
1152 115.200 Bd
1500 150.000 Bd
2500 250.000 Bd
3750 375.000 Bd
7500 750.000 Bd
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01902 | Diagnostics X6: Max. baud rate
Data type: UNSIGNED_16
Index: 22673
d
= 5891
h
Parameter | Name:
C01903 | Diagnostics X6: Change baud rate
Data type: UNSIGNED_8
Index: 22672
d
= 5890
h
New baud rate determination at the diagnostic interface X6
Selection list (Lenze setting printed in bold)
0 Ignore changes
1Negotiate baud rate
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01905 | Diagnostics X6: Current baud rate
Data type: UNSIGNED_32
Index: 22670
d
= 588E
h
Current baud rate at the diagnostic interface X6
Display range (min. value | unit | max. value)
0 Bd 3000000
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C02200 | LS_WriteParamList: Function
Data type: UNSIGNED_8
Index: 22375
d
= 5767
h
From version 12.00.00
Configuration of which parameter lists are to be subject to the "Parameter change-over
" function.
Selection list
0Off
1On
Subcodes Lenze setting Info
C02200/1 1: On Definable parameter list
C02200/2 0: Off Motor data parameter list
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
