Lenze 8400 - Page 1104

15 Parameter reference
15.2 Parameter list
1104
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02210
C02212
C02213
Parameter | Name:
C02210 | LS_WriteParamList: Motor control
Data type: UNSIGNED_8
Index: 22365
d
= 575D
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Selection list
2SC: Servo control ASM
3 SLPSM: Sensorless PSM
4 SLVC: Vector control
6 VFCplus: V/f linear
7 VFCplus: V/f linear + encoder
8 VFCplus: V/f quadr
9 VFCplus: V/f quadr + encoder
10 VFCplus: V/f definable
11 VFCplusEco: V/f energy-saving
Subcodes Lenze setting Info
C02210/1 6: VFCplus: V/f linear LS_WriteParamList
: c6_val1
C02210/2 6: VFCplus: V/f linear LS_WriteParamList
: c6_val2
C02210/3 6: VFCplus: V/f linear LS_WriteParamList
: c6_val3
C02210/4 6: VFCplus: V/f linear LS_WriteParamList
: c6_val3
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C02212 | LS_WriteParamList: VFC: V/f base frequency
Data type: UNSIGNED_16
Index: 22363
d
= 575B
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
7.5 Hz 2600.0
Subcodes Lenze setting Info
C02212/1 50.0 Hz LS_WriteParamList: c15_val1
C02212/2 50.0 Hz LS_WriteParamList
: c15_val2
C02212/3 50.0 Hz LS_WriteParamList
: c15_val3
C02212/4 50.0 Hz LS_WriteParamList: c15_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
Parameter | Name:
C02213 | LS_WriteParamList: VFC: Vmin boost
Data type: UNSIGNED_16
Index: 22362
d
= 575A
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.00 % 100.00
Subcodes Lenze setting Info
C02213/1 1.60 % LS_WriteParamList
: c16_val1
C02213/2 1.60 % LS_WriteParamList
: c16_val2
C02213/3 1.60 % LS_WriteParamList
: c16_val3
C02213/4 1.60 % LS_WriteParamList
: c16_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
