Lenze 8400 - Page 1110

15 Parameter reference
15.2 Parameter list
1110
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02227
C02228
C02229
Parameter | Name:
C02227 | LS_WriteParamList: SC: Vp field controller
Data type: UNSIGNED_16
Index: 22348
d
= 574C
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.00 500.00
Subcodes Lenze setting Info
C02227/1 12.80 LS_WriteParamList
: c77_val1
C02227/2 12.80 LS_WriteParamList
: c77_val2
C02227/3 12.80 LS_WriteParamList
: c77_val3
C02227/4 12.80 LS_WriteParamList
: c77_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C02228 | LS_WriteParamList: SC: Tn field controller
Data type: UNSIGNED_16
Index: 22347
d
= 574B
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.0 ms 6000.0
Subcodes Lenze setting Info
C02228/1 256.0 ms LS_WriteParamList
: c78_val1
C02228/2 256.0 ms LS_WriteParamList
: c78_val2
C02228/3 256.0 ms LS_WriteParamList
: c78_val3
C02228/4 256.0 ms LS_WriteParamList
: c78_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
Parameter | Name:
C02229 | LS_WriteParamList: SC: Settings
Data type: UNSIGNED_8
Index: 22346
d
= 574A
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Selection list
0Off
1On
Subcodes Lenze setting Info
C02229/1 0: Off LS_WriteParamList
: c79_s1_val1
C02229/2 0: Off LS_WriteParamList
: c79_s1_val2
C02229/3 0: Off LS_WriteParamList
: c79_s1_val3
C02229/4 0: Off LS_WriteParamList
: c79_s1_val4
C02229/5 1: On LS_WriteParamList
: c79_s2_val1
C02229/6 1: On LS_WriteParamList
: c79_s2_val2
C02229/7 1: On LS_WriteParamList
: c79_s2_val3
C02229/8 1: On LS_WriteParamList
: c79_s2_val4
C02229/9 0: Off LS_WriteParamList
: c79_s3_val1
C02229/10 0: Off LS_WriteParamList
: c79_s3_val2
C02229/11 0: Off LS_WriteParamList
: c79_s3_val3
C02229/12 0: Off LS_WriteParamList
: c79_s3_val4
