Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1111
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02230
C02231
C02232
C02229/13 1: On LS_WriteParamList
: c79_s4_val1
C02229/14 1: On LS_WriteParamList
: c79_s4_val2
C02229/15 1: On LS_WriteParamList
: c79_s4_val3
C02229/16 1: On LS_WriteParamList
: c79_s4_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C02229 | LS_WriteParamList: SC: Settings
Data type: UNSIGNED_8
Index: 22346
d
= 574A
h
Parameter | Name:
C02230 | LS_WriteParamList: Override point of field weakening
Data type: INTEGER_16
Index: 22345
d
= 5749
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
-500 Hz 500
Subcodes Lenze setting Info
C02230/1 0 Hz LS_WriteParamList
: c80_val1
C02230/2 0 Hz LS_WriteParamList
: c80_val2
C02230/3 0 Hz LS_WriteParamList
: c80_val3
C02230/4 0 Hz LS_WriteParamList
: c80_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C02231 | LS_WriteParamList: Rated motor power
Data type: UNSIGNED_16
Index: 22344
d
= 5748
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.00 kW 500.00
Subcodes Lenze setting Info
C02231/1 11.00 kW LS_WriteParamList
: c81_val1
C02231/2 11.00 kW LS_WriteParamList
: c81_val2
C02231/3 11.00 kW LS_WriteParamList: c81_val3
C02231/4 11.00 kW LS_WriteParamList
: c81_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C02232 | LS_WriteParamList: Motor rotor resistance
Data type: UNSIGNED_32
Index: 22343
d
= 5747
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0 mOhm 200000
Subcodes Lenze setting Info
C02232/1 276 mOhm LS_WriteParamList
: c82_val1
C02232/2 276 mOhm LS_WriteParamList
: c82_val2
C02232/3 276 mOhm LS_WriteParamList
: c82_val3
C02232/4 276 mOhm LS_WriteParamList
: c82_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
