15 Parameter reference
15.2 Parameter list
1112
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02233
C02234
C02236
Parameter | Name:
C02233 | LS_WriteParamList: Motor stator resistance
Data type: UNSIGNED_32
Index: 22342
d
= 5746
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0 mOhm 200000
Subcodes Lenze setting Info
C02233/1 330 mOhm LS_WriteParamList
: c84_val1
C02233/2 330 mOhm LS_WriteParamList
: c84_val2
C02233/3 330 mOhm LS_WriteParamList
: c84_val3
C02233/4 330 mOhm LS_WriteParamList
: c84_val4
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C02234 | LS_WriteParamList: Motor stator leakage inductance
Data type: UNSIGNED_16
Index: 22341
d
= 5745
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.00 mH 650.00
Subcodes Lenze setting Info
C02234/1 3.50 mH LS_WriteParamList
: c85_val1
C02234/2 3.50 mH LS_WriteParamList
: c85_val2
C02234/3 3.50 mH LS_WriteParamList
: c85_val3
C02234/4 3.50 mH LS_WriteParamList
: c85_val4
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C02236 | LS_WriteParamList: Rated motor speed
Data type: UNSIGNED_16
Index: 22339
d
= 5743
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
50 rpm 60000
Subcodes Lenze setting Info
C02236/1 1460 rpm LS_WriteParamList
: c87_val1
C02236/2 1460 rpm LS_WriteParamList
: c87_val2
C02236/3 1460 rpm LS_WriteParamList
: c87_val3
C02236/4 1460 rpm LS_WriteParamList
: c87_val4
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
