Lenze 8400 - Page 1113

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1113
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02237
C02238
C02239
Parameter | Name:
C02237 | LS_WriteParamList: Rated motor current
Data type: UNSIGNED_16
Index: 22338
d
= 5742
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.20 A 320.00
Subcodes Lenze setting Info
C02237/1 21.00 A LS_WriteParamList
: c88_val1
C02237/2 21.00 A LS_WriteParamList
: c88_val2
C02237/3 21.00 A LS_WriteParamList
: c88_val3
C02237/4 21.00 A LS_WriteParamList
: c88_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C02238 | LS_WriteParamList: Rated motor frequency
Data type: UNSIGNED_16
Index: 22337
d
= 5741
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
1 Hz 1000
Subcodes Lenze setting Info
C02238/1 50 Hz LS_WriteParamList
: c89_val1
C02238/2 50 Hz LS_WriteParamList
: c89_val2
C02238/3 50 Hz LS_WriteParamList
: c89_val3
C02238/4 50 Hz LS_WriteParamList
: c89_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C02239 | LS_WriteParamList: Rated motor voltage
Data type: UNSIGNED_16
Index: 22336
d
= 5740
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0 V 5000
Subcodes Lenze setting Info
C02239/1 400 V LS_WriteParamList
: c90_val1
C02239/2 400 V LS_WriteParamList
: c90_val2
C02239/3 400 V LS_WriteParamList
: c90_val3
C02239/4 400 V LS_WriteParamList
: c90_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
