15 Parameter reference
15.2 Parameter list
1114
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02240
C02241
C02242
Parameter | Name:
C02240 | LS_WriteParamList: Motor cosine phi
Data type: UNSIGNED_8
Index: 22335
d
= 573F
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.20 1.00
Subcodes Lenze setting Info
C02240/1 0.85 LS_WriteParamList
: c91_val1
C02240/2 0.85 LS_WriteParamList
: c91_val2
C02240/3 0.85 LS_WriteParamList
: c91_val3
C02240/4 0.85 LS_WriteParamList
: c91_val4
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C02241 | LS_WriteParamList: Motor magnetizing inductance
Data type: UNSIGNED_16
Index: 22334
d
= 573E
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.0 mH 6500.0
Subcodes Lenze setting Info
C02241/1 81.0 mH LS_WriteParamList
: c92_val1
C02241/2 81.0 mH LS_WriteParamList
: c92_val2
C02241/3 81.0 mH LS_WriteParamList
: c92_val3
C02241/4 81.0 mH LS_WriteParamList
: c92_val4
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 10
Parameter | Name:
C02242 | LS_WriteParamList: Motor magnetising current
Data type: UNSIGNED_16
Index: 22333
d
= 573D
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.00 A 320.00
Subcodes Lenze setting Info
C02242/1 8.50 A LS_WriteParamList
: c95_val1
C02242/2 8.50 A LS_WriteParamList
: c95_val2
C02242/3 8.50 A LS_WriteParamList
: c95_val3
C02242/4 8.50 A LS_WriteParamList
: c95_val4
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
