Lenze 8400 - Page 1115

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1115
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02244
C02245
C02246
Parameter | Name:
C02244 | LS_WriteParamList: Auto-DCB: Hold time
Data type: UNSIGNED_32
Index: 22331
d
= 573B
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.000 s 999.000
Subcodes Lenze setting Info
C02244/1 0.500 s LS_WriteParamList
: c106_val1
C02244/2 0.500 s LS_WriteParamList
: c106_val2
C02244/3 0.500 s LS_WriteParamList
: c106_val3
C02244/4 0.500 s LS_WriteParamList
: c106_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C02245 | LS_WriteParamList: DC braking: Hold time
Data type: UNSIGNED_32
Index: 22330
d
= 573A
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.000 s 999.000
Subcodes Lenze setting Info
C02245/1 998.999 s LS_WriteParamList
: c107_val1
C02245/2 998.999 s LS_WriteParamList
: c107_val2
C02245/3 998.999 s LS_WriteParamList
: c107_val3
C02245/4 998.999 s LS_WriteParamList
: c107_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C02246 | LS_WriteParamList: Setting of motor overload (I²xt)
Data type: INTEGER_16
Index: 22329
d
= 5739
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.00 % 250.00
Subcodes Lenze setting Info
C02246/1 100.00 % LS_WriteParamList
: c120_val1
C02246/2 100.00 % LS_WriteParamList
: c120_val2
C02246/3 100.00 % LS_WriteParamList
: c120_val3
C02246/4 100.00 % LS_WriteParamList
: c120_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
