Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1109
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02224
C02225
C02226
Parameter | Name:
C02224 | LS_WriteParamList: Imax/M controller reset time
Data type: UNSIGNED_16
Index: 22351
d
= 574F
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0 ms 9990
Subcodes Lenze setting Info
C02224/1 65 ms LS_WriteParamList
: c74_s1_val1
C02224/2 65 ms LS_WriteParamList
: c74_s1_val2
C02224/3 65 ms LS_WriteParamList
: c74_s1_val3
C02224/4 65 ms LS_WriteParamList
: c74_s1_val4
C02224/5 30 ms LS_WriteParamList
: c74_s2_val1
C02224/6 30 ms LS_WriteParamList
: c74_s2_val2
C02224/7 30 ms LS_WriteParamList
: c74_s2_val3
C02224/8 30 ms LS_WriteParamList
: c74_s2_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C02225 | LS_WriteParamList: Vp current controller
Data type: UNSIGNED_16
Index: 22350
d
= 574E
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.00 V/A 500.00
Subcodes Lenze setting Info
C02225/1 7.00 V/A LS_WriteParamList
: c75_val1
C02225/2 7.00 V/A LS_WriteParamList
: c75_val2
C02225/3 7.00 V/A LS_WriteParamList
: c75_val3
C02225/4 7.00 V/A LS_WriteParamList
: c75_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C02226 | LS_WriteParamList: Ti current controller
Data type: UNSIGNED_16
Index: 22349
d
= 574D
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.00 ms 500.00
Subcodes Lenze setting Info
C02226/1 10.61 ms LS_WriteParamList
: c76_val1
C02226/2 10.61 ms LS_WriteParamList
: c76_val2
C02226/3 10.61 ms LS_WriteParamList
: c76_val3
C02226/4 10.61 ms LS_WriteParamList
: c76_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
