Lenze 8400 - Page 1108

15 Parameter reference
15.2 Parameter list
1108
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02222
C02223
C02221/6 50.0 ms LS_WriteParamList
: c71_s2_val2
C02221/7 50.0 ms LS_WriteParamList
: c71_s2_val3
C02221/8 50.0 ms LS_WriteParamList
: c71_s2_val4
C02221/9 50.0 ms LS_WriteParamList
: c71_s3_val1
C02221/10 50.0 ms LS_WriteParamList
: c71_s3_val2
C02221/11 50.0 ms LS_WriteParamList
: c71_s3_val3
C02221/12 50.0 ms LS_WriteParamList
: c71_s3_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
Parameter | Name:
C02221 | LS_WriteParamList: Ti speed controller
Data type: UNSIGNED_16
Index: 22354
d
= 5752
h
Parameter | Name:
C02222 | LS_WriteParamList: SC: Tdn speed controller
Data type: UNSIGNED_16
Index: 22353
d
= 5751
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.00 ms 3.00
Subcodes Lenze setting Info
C02222/1 0.00 ms LS_WriteParamList
: c72_val1
C02222/2 0.00 ms LS_WriteParamList
: c72_val2
C02222/3 0.00 ms LS_WriteParamList
: c72_val3
C02222/4 0.00 ms LS_WriteParamList
: c72_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C02223 | LS_WriteParamList: Imax/M controller gain
Data type: UNSIGNED_16
Index: 22352
d
= 5750
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.00 100.00
Subcodes Lenze setting Info
C02223/1 0.25 LS_WriteParamList
: c73_s1_val1
C02223/2 0.25 LS_WriteParamList
: c73_s1_val2
C02223/3 0.25 LS_WriteParamList
: c73_s1_val3
C02223/4 0.25 LS_WriteParamList
: c73_s1_val4
C02223/5 1.25 LS_WriteParamList
: c73_s2_val1
C02223/6 1.25 LS_WriteParamList
: c73_s2_val2
C02223/7 1.25 LS_WriteParamList
: c73_s2_val3
C02223/8 1.25 LS_WriteParamList
: c73_s2_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
