Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1107
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02219
C02220
C02221
Parameter | Name:
C02219 | LS_WriteParamList: DC braking: Current
Data type: INTEGER_16
Index: 22356
d
= 5754
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.00 % 200.00
Subcodes Lenze setting Info
C02219/1 50.00 % LS_WriteParamList
: c36_val1
C02219/2 50.00 % LS_WriteParamList
: c36_val2
C02219/3 50.00 % LS_WriteParamList
: c36_val3
C02219/4 50.00 % LS_WriteParamList
: c36_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C02220 | LS_WriteParamList: Vp speed controller
Data type: UNSIGNED_16
Index: 22355
d
= 5753
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.00 600.00
Subcodes Lenze setting Info
C02220/1 15.00 LS_WriteParamList
: c70_s1_val1
C02220/2 15.00 LS_WriteParamList
: c70_s1_val2
C02220/3 15.00 LS_WriteParamList
: c70_s1_val3
C02220/4 15.00 LS_WriteParamList
: c70_s1_val4
C02220/5 6.00 LS_WriteParamList
: c70_s2_val1
C02220/6 6.00 LS_WriteParamList
: c70_s2_val2
C02220/7 6.00 LS_WriteParamList
: c70_s2_val3
C02220/8 6.00 LS_WriteParamList
: c70_s2_val4
C02220/9 3.00 LS_WriteParamList: c70_s3_val1
C02220/10 3.00 LS_WriteParamList
: c70_s3_val2
C02220/11 3.00 LS_WriteParamList
: c70_s3_val3
C02220/12 3.00 LS_WriteParamList: c70_s3_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C02221 | LS_WriteParamList: Ti speed controller
Data type: UNSIGNED_16
Index: 22354
d
= 5752
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.0 ms 6000.0
Subcodes Lenze setting Info
C02221/1 100.0 ms LS_WriteParamList
: c71_s1_val1
C02221/2 100.0 ms LS_WriteParamList
: c71_s1_val2
C02221/3 100.0 ms LS_WriteParamList
: c71_s1_val3
C02221/4 100.0 ms LS_WriteParamList
: c71_s1_val4
C02221/5 50.0 ms LS_WriteParamList
: c71_s2_val1
