Lenze 8400 - Page 1124

15 Parameter reference
15.2 Parameter list
1124
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02289
C02290
C02291
Parameter | Name:
C02289 | LS_WriteParamList: VFC-ECO: Minimum voltage U/f
Data type: INTEGER_16
Index: 22286
d
= 570E
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
20.00 % 100.00
Subcodes Lenze setting Info
C02289/1 20.00 % LS_WriteParamList
: c977_val1
C02289/2 20.00 % LS_WriteParamList
: c977_val2
C02289/3 20.00 % LS_WriteParamList
: c977_val3
C02289/4 20.00 % LS_WriteParamList
: c977_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C02290 | LS_WriteParamList: VFC-ECO: Voltage reduction ramp
Data type: UNSIGNED_8
Index: 22285
d
= 570D
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.0 s 5.0
Subcodes Lenze setting Info
C02290/1 0.8 s LS_WriteParamList
: c982_val1
C02290/2 0.8 s LS_WriteParamList
: c982_val2
C02290/3 0.8 s LS_WriteParamList
: c982_val3
C02290/4 0.8 s LS_WriteParamList
: c982_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
Parameter | Name:
C02291 | LS_WriteParamList: SLVC: Field current controller gain
Data type: INTEGER_16
Index: 22284
d
= 570C
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.00 % 20.00
Subcodes Lenze setting Info
C02291/1 0.50 % LS_WriteParamList
: c985_val1
C02291/2 0.50 % LS_WriteParamList
: c985_val2
C02291/3 0.50 % LS_WriteParamList
: c985_val3
C02291/4 0.50 % LS_WriteParamList
: c985_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
