Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1125
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02292
C02293
C02294
Parameter | Name:
C02292 | LS_WriteParamList: SLVC: Cross current controller gain
Data type: INTEGER_16
Index: 22283
d
= 570B
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.00 % 20.00
Subcodes Lenze setting Info
C02292/1 0.00 % LS_WriteParamList
: c986_val1
C02292/2 0.00 % LS_WriteParamList
: c986_val2
C02292/3 0.00 % LS_WriteParamList
: c986_val3
C02292/4 0.00 % LS_WriteParamList
: c986_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C02293 | LS_WriteParamList: Inverter motor brake: nAdd
Data type: INTEGER_16
Index: 22282
d
= 570A
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0 rpm 1000
Subcodes Lenze setting Info
C02293/1 80 rpm LS_WriteParamList
: c987_val1
C02293/2 80 rpm LS_WriteParamList
: c987_val2
C02293/3 80 rpm LS_WriteParamList
: c987_val3
C02293/4 80 rpm LS_WriteParamList
: c987_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C02294 | LS_WriteParamList: Inverter motor brake: PT1 filter time
Data type: INTEGER_16
Index: 22281
d
= 5709
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.0 ms 100.0
Subcodes Lenze setting Info
C02294/1 0.0 ms LS_WriteParamList
: c988_val1
C02294/2 0.0 ms LS_WriteParamList
: c988_val2
C02294/3 0.0 ms LS_WriteParamList
: c988_val3
C02294/4 0.0 ms LS_WriteParamList
: c988_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
