15 Parameter reference
15.2 Parameter list
1146
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02855
C02859
C02864
C02853/5 100 % PSM: Lss saturation characteristic
C02853/6 100 % PSM: Lss saturation characteristic
C02853/7 100 % PSM: Lss saturation characteristic
C02853/8 100 % PSM: Lss saturation characteristic
C02853/9 100 % PSM: Lss saturation characteristic
C02853/10 100 % PSM: Lss saturation characteristic
C02853/11 100 % PSM: Lss saturation characteristic
C02853/12 100 % PSM: Lss saturation characteristic
C02853/13 100 % PSM: Lss saturation characteristic
C02853/14 100 % PSM: Lss saturation characteristic
C02853/15 100 % PSM: Lss saturation characteristic
C02853/16 100 % PSM: Lss saturation characteristic
C02853/17 100 % PSM: Lss saturation characteristic
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C02853 | PSM: Lss saturation characteristic
Data type: UNSIGNED_8
Index: 21722
d
= 54DA
h
Parameter | Name:
C02855 | PSM: Imax Lss saturation characteristic
Data type: UNSIGNED_16
Index: 21720
d
= 54D8
h
From version 10.00.00
Current-dependent stator leakage inductance Lss(I)
Setting range (min. value | unit | max. value) Lenze setting
0.0 A 3000.0 3000.0 A
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
Parameter | Name:
C02859 | PSM: Activate Lss saturation char.
Data type: UNSIGNED_8
Index: 21716
d
= 54D4
h
From version 10.00.00
Current-dependent stator leakage inductance Lss(I)
Selection list (Lenze setting printed in bold)
0Off
1On
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C02864 | MCTRL: Optimisiations
Data type: UNSIGNED_16
Index: 21711
d
= 54CF
h
From version 14.00.00
Activation of special functions of the internal motor control
Setting range (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 Motor temp. 90° for operation
without KTY
1 ≡ Warm machine. In case the temperature tracking is
not active, a motor temperature of 90 °C is assumed.
