Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1145
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02843
C02844
C02845
C02853
Parameter | Name:
C02843 | FreqInxx: Gain
Data type: INTEGER_16
Index: 21732
d
= 54E4
h
From version 02.00.00
Gain for digital frequency inputs
Using DI1(6) and DI2(7) as frequency inputs
Setting range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Lenze setting Info
C02843/1 100.00 % FreqIn12: Gain
C02843/2 100.00 % FreqIn67: Gain
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C02844 | FreqIn12: Function
Data type: UNSIGNED_8
Index: 21731
d
= 54E3
h
From version 06.00.00
Output of the encoder position of the DI1/DI2 frequency input
Selection list
0Loading with level
1Loading with edge
2 Loading with level + reset
Subcodes Lenze setting Info
C02844/1 0: Loading with level FreqIn12: PosIn function
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C02845 | FreqIn12: PosIn comparison value
Data type: INTEGER_32
Index: 21730
d
= 54E2
h
From version 06.00.00
Output of the encoder position of the DI1/DI2 frequency input
Setting range (min. value | unit | max. value) Lenze setting
0 Incr. 2147418112 0incr.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C02853 | PSM: Lss saturation characteristic
Data type: UNSIGNED_8
Index: 21722
d
= 54DA
h
From version 10.00.00
Current-dependent stator leakage inductance Lss(I)
Setting range (min. value | unit | max. value)
0 % 255
Subcodes Lenze setting Info
C02853/1 100 % PSM: Lss saturation characteristic
C02853/2 100 % PSM: Lss saturation characteristic
C02853/3 100 % PSM: Lss saturation characteristic
C02853/4 100 % PSM: Lss saturation characteristic
