Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1155
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02879
C02993
C02994
C02995
Parameter | Name:
C02879 | Slip calculation from equivalent circuit diagram
Data type: UNSIGNED_16
Index: 21696
d
= 54C0
h
From version 11.00.00
In order to achieve a better speed stability and torque accuracy, the slip calculation can be either derived from the
motor nameplate data (e.g. rated motor speed) or the motor equivalent circuit diagram data (stator resistance, rotor
resistance etc.).
Setting range (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 SLVC Slip calculation for SLVC
Bit 1 SC ASM Slip calculation for SC
Bit 2 Reserved
Bit 3 Reserved
Bit 4 Reserved
Bit 5 Reserved
Bit 6 Reserved
Bit 7 Reserved
Bit 8 Reserved
Bit 9 Reserved
Bit 10 Reserved
Bit 11 Reserved
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Reserved
Bit 15 Reserved
Subcodes Lenze setting Info
C02879/1 0x0000 Slip calculation from equivalent circuit diagram
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C02993 | FB xy position
Data type: UNSIGNED_32
Index: 21582
d
= 544E
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C02994 | FB xy position
Data type: UNSIGNED_32
Index: 21581
d
= 544D
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C02995 | FB display InputOutput
Data type: UNSIGNED_32
Index: 21580
d
= 544C
h
This code is for device-internal use only and must not be written to by the user!
