17 Function library
17.1 Function blocks | L_Curve_2
1337
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01028/1...32 -32767 32767 X values for characteristic function
• Subcodes 1 ... 32 correspond to
interpolation point values
X1 ... X32.
• ±16384 ≡ ±100 %
•Lenze setting: 0
See description of L_Curve_1:
Function 3: nOut_a = f(table)
C01029/1...32 -32767 32767 Y values for characteristic function
• Subcodes 1 ... 32 correspond to
interpolation point values
Y1 ... Y32.
• ±16384 ≡ ±100 %
•Lenze setting: 0
See description of L_Curve_1:
Function 3: nOut_a = f(table)
 For a detailed functional description see L_Curve_1.
Parameters Possible settings Info
