Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1478
17 Function library
17.1 Function blocks | L_PhiIntegrator_1
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Outputs
Parameters
Designator
Data type
Value/meaning
dnOut32_p
DINT
Integrator value (32 bits)
bOvfl32
BOOL
Status signal "overflow (32 bits)"
TRUE Overflow
nOut16
INT
Integrator value (16 bits)
bOvfl16
BOOL
Status signal "overflow (16 bits)"
TRUE Overflow
bInitDone
BOOL
Status signal "Initialisation completed"
TRUE Integrator is initialised
nSpeedGearAdd_v
INT
Resulting speed with additive speed
(nSet_v * gearbox factor + nSpeedAdd_v)
nSpeedGear_v
INT
Resulting speed without additive speed
(nSet_v * gearbox factor)
Parameters Possible settings Info
C01067/1
Invert. gearbox nSet_v
0not inverted
1inverted
2 Automatically from MCK
