Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1049
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01067
C01068
Parameter | Name:
C01067 | Inversion of gearbox stages
Data type: UNSIGNED_8
Index: 23508
d
= 5BD4
h
From version 11.00.00
Selection list
0not inverted
1inverted
2 Automatically from MCK
Subcodes Lenze setting Info
C01067/1 0: Not inverted L_PhiIntegrator_1
: Invert. gearbox nSet_v
C01067/2 0: Not inverted L_DFSET_1
: Invert. gearbox nSet_v
C01067/3 0: Not inverted L_CalcDiameter_1
: Invert. gearbox nMotorSpeedAct_v
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01068 | L_SwitchPoint_1: Invert
Data type: UNSIGNED_16
Index: 23507
d
= 5BD3
h
From version 12.00.00
Setting range (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 Invert Output1 Bit set = inversion active
Bit 1 Invert Output2
Bit 2 Invert Output3
Bit 3 Invert Output4
Bit 4 Reserved
Bit 5 Reserved
Bit 6 Reserved
Bit 7 Reserved
Bit 8 Reserved
Bit 9 Reserved
Bit 10 Reserved
Bit 11 Reserved
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Reserved
Bit 15 Reserved
Subcodes Lenze setting Info
C01068/1 0x0000 L_SwitchPoint_1
: Inversion of outputs
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
