7 Technology applications
7.2 TA "Actuating drive speed"
384
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
nDCVoltage_a
INT
Actual DC-bus voltage
• Scaling: 16384 ≡ 1000 V
nMotorVoltage_a
INT
Current motor voltage/inverter output voltage
• Scaling: 16384 ≡ 1000 V
MCK basic functions
bMBrakeReleaseOut
BOOL
Holding brake control: Trigger signal for the holding brake control switching
element via a digital output
•Use bit0 in C02582
to activate inverted switching element triggering.
FALSE Apply brake.
TRUE Release brake.
bMBrakeReleased
BOOL
Holding brake control: "Brake released" considering the brake release time
• When the holding brake is triggered to close, bMBrakeReleased is immediately set
to FALSE even if the brake closing time has not yet elapsed!
TRUE Brake released (after the brake release time has expired).
GP: GeneralPurpose
The following outputs are interconnected with logic/arithmetic functions on application level for free usage.
"GeneralPurpose" functions
nGPAnalogSwitchInOut_a
INT
Analog switch: Output signal
nGPArithmetikOut_a
INT
Arithmetic: Output signal
nGPMulDivOut_a
INT
Multiplication/Division: Output signal
bGPDigitalDelayOut
BOOL
Binary delay element: Output signal
bGPLogicOut
BOOL
Binary logic: Output signal
bGPCompareOut
BOOL
Analog comparison: Output signal
bGPSignalOut1
...
bGPSignalOut4
BOOL
Binary signal monitor: Output signals
• The signal sources to be output are selected in C00411/1...4
.
• A bit coded inversion of the output signals can be parameterised in C00412
.
nGPSignalOut1_a
...
nGPSignalOut4_a
BOOL
Analog signal monitor: Output signals
• The signal sources to be output are selected in C00410/1...4
.
• Gain and offset for each output signal can be parameterised in C00413/1...8
.
bGPDFlipFlop_Out
BOOL
D-FlipFlop: Output signal
bGPDFlipFlop_NegOut
BOOL
D-FlipFlop: Negated output signal
Free outputs
The following outputs can freely be interconnected on the application level.
The signals from the application level can be transferred to the I/O level via these outputs.
bFreeOut1 ... bFreeOut8
BOOL
Free outputs for digital signals
wFreeOut1 ... wFreeOut4
WORD
Free outputs for 16-bit signals
Designator
Data type
Value/meaning
