Lenze 8400 - Page 443

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 443
7 Technology applications
7.4 TA "Table positioning"
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
nAccOverride_a
INT
Value for Acceleration override
• Percentage multiplier for the currently active acceleration.
• 16384 ≡ 100 % of the parameterised acceleration of the corresponding operating
mode.
• If the override value is 0 %, acceleration ceases.
bHomeStartStop
BOOL
Homing: Start/stop homing
TRUE Start homing
TRUEFALSE Stop homing
bHomeSetPosition
BOOL
Homing: Set home position
TRUE Set home position
bHomeResetPosition
BOOL
Homing: Reset home position
TRUE Reset the "Reference known" status
bHomeMark
BOOL
Homing: Input for reference switch (pre-switch off mark)
• This input responds to the FALSE status (fail-safe) and is to be connected to the
corresponding digital input to which the reference switch is connected.
bPosSetProfilePosition
BOOL
Position teaching: MCK setpoint position
TRUE Teach MCK setpoint position into the selected profile.
bPosSetActualPosition
BOOL
Position teaching: Current position
TRUE Teach current position into the selected profile.
bPosExecute
BOOL
Positioning: Start travelling
FALSETRUE Execute selected profile
bPosFinishTarget
BOOL
Positioning: Complete cancelled profile
FALSETRUE A positioning process previously cancelled, e.g. by bPosStop or due to
a device error, is resumed by travelling to the original target.
bPosDisableFollowProfile
BOOL
Positioning: Do not execute sequence profile (switch-off profile linkage)
TRUE Evaluation of the sequence profile number parameterised in
C01307/1...15
for the selected profile is suppressed.
bPosStop
BOOL
Positioning: Cancel travelling
TRUE Stop positioning
From version 11.00.00, more travel requests will be inhibited
("PosExecute" will be blocked).
Designator
Data type
Information/possible settings
