Lenze 8400 - Page 840

15 Parameter reference
15.2 Parameter list
840
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00130
C00131
C00133
C00134
C00136
Parameter | Name:
C00130 | Rated power - brake resistor
Data type: UNSIGNED_16
Index: 24445
d
= 5F7D
h
From version 02.00.00
Rated power of the connected brake resistor
• The value to be entered can be obtained from the nameplate of the brake resistor.
Setting range (min. value | unit | max. value) Lenze setting
0 W 65535 power-related (see table
)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00131 | Rated heat amount of brake resist.
Data type: UNSIGNED_16
Index: 24444
d
= 5F7C
h
Heat quantity of the connected brake resistor
• Lenze brake resistor: The value is preset to the adapted minimum Lenze brake resistance.
• Brake resistor from a third party manufacturer: The value to be entered can be obtained from the nameplate of
the brake resistor.
Setting range (min. value | unit | max. value) Lenze setting
0.0 kWs 6553.5 power-related (see table
)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
Parameter | Name:
C00133 | Brake resistor utilisation
Data type: UNSIGNED_16
Index: 24442
d
= 5F7A
h
Display of the utilisation of the connected brake resistor
Display range (min. value | unit | max. value)
0 % 65535
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00134 | L_NSet_1: Ramp smoothing
Data type: UNSIGNED_8
Index: 24441
d
= 5F79
h
The L_NSet_1 FB: Configuration of the ramp rounding for the main setpoint
Selection list (Lenze setting printed in bold) Info
0Off Ramp rounding deactivated
1 PT1 behaviour Ramp rounding with PT1 behaviour
• The corresponding S-ramp time must be set in
C00182
.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00136 | Communication control words
Data type: UNSIGNED_16
Index: 24439
d
= 5F77
h
Control words of the communication interfaces
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
