15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00137
Value is bit-coded:
Bit 0 SwitchOn
Bit 1 DisableVoltage
Bit 2 SetQuickStop
Bit 3 EnableOperation
Bit 4 ModeSpecific_1
Bit 5 ModeSpecific_2
Bit 6 ModeSpecific_3
Bit 7 ResetFault
Bit 8 SetHalt
Bit 9 Reserved_1
Bit 10 Reserved_2
Bit 11 LenzeSpecific_1
Bit 12 LenzeSpecific_2
Bit 13 LenzeSpecific_3
Bit 14 SetFail
Bit 15 LenzeSpecific_4
Subcodes Info
C00136/1 MCI control word
• Control word of the MCI communication interface
(communication module)
C00136/2 CAN control word
• Control word of the CAN communication interface
(CAN on board)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00136 | Communication control words
Data type: UNSIGNED_16
Index: 24439
d
= 5F77
h
Parameter | Name:
C00137 | Device status
Data type: UNSIGNED_16
Index: 24438
d
= 5F76
h
Display of the current device status
