15 Parameter reference
15.2 Parameter list
842
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00138
Selection list (read only)
0 FirmwareUpdate
1 Init
2 Ident
3 ReadyToSwitchON
4 SwitchedON
5 OperationEnable
6 Warning
7 Trouble
8 Fault
9 TroubleQSP
10 SafeTorqueOff
11 SystemFail
12 Reserved_1
13 Reserved_2
14 Reserved_3
15 Reserved_4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00137 | Device status
Data type: UNSIGNED_16
Index: 24438
d
= 5F76
h
Parameter | Name:
C00138 | Internal control signals
Data type: UNSIGNED_16
Index: 24437
d
= 5F75
h
Bit coded display of internal control signals of different sources
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded:
Bit 0 Reserved
Bit 1 DisableVoltage
Bit 2 SetQuickStop
Bit 3 EnableOperation
Bit 4 InitFinishedOK
Bit 5 ModeSpecific_2
Bit 6 ModeSpecific_3
Bit 7 ResetFault
Bit 8 SetHalt
Bit 9 FirmwareUpdate
Bit 10 MotorIdent
Bit 11 SetMessage
Bit 12 SetIMP
Bit 13 SetSystemFail
Bit 14 SetFail
Bit 15 SetFailQSP
