Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 843
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00142
C00144
C00148
Subcodes Info
C00138/1 SYS control signals
C00138/2 MCK control signals
C00138/3 FWM control signals
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00138 | Internal control signals
Data type: UNSIGNED_16
Index: 24437
d
= 5F75
h
Parameter | Name:
C00142 | Auto-start option
Data type: UNSIGNED_8
Index: 24433
d
= 5F71
h
Starting performance of the inverter after mains connection, undervoltage, loading of the Lenze setting as well as
a reset of "Trouble" or "Fault" can be parameterised individually.
Automatic restart after mains connection/fault...
Setting range (min. hex value | max. hex value) Lenze setting
0x00 0xFF 0x19 (decimal: 25)
Value is bit-coded: ( =bit set) Info
Bit 0  Inhibit at power-on
Bit 1  Inhibit at trouble
Bit 2  Inhibit at fault
Bit 3  Inhibit at undervoltage
Bit 4  Inhibit at Lenze setting From version 06.00.00
Bit 5  Reserved
Bit 6  Reserved
Bit 7  Reserved
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00144 | Switching freq. reduct. (Temp.)
Data type: UNSIGNED_8
Index: 24431
d
= 5F6F
h
Activation of the automatic switching frequency reduction if the temperature is too high
Selection list (Lenze setting printed in bold) Info
0 Off Automatic switching frequency reduction deactivated
1On Automatic switching frequency reduction activated
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00148 | LS_DriveInterface: Error message config.
Data type: UNSIGNED_16
Index: 24427
d
= 5F6B
h
From version 04.00.00
Selection of the device statuses for which the bCollectedFail group error output of SB LS_DriveInterface
is to be set
to TRUE.
Setting range (min. hex value | max. hex value) Lenze setting
0x0000 0xFFFF 0x0030 (decimal: 48)
Value is bit-coded: ( =bit set) Info
Bit 0  SafeTorqueOff
Bit 1  ReadyToSwitchOn
