Lenze 8400 - Page 844

15 Parameter reference
15.2 Parameter list
844
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00150
Bit 2  SwitchedOn
Bit 3  TroubleQSP From version 06.00.00
Bit 4  Trouble
Bit 5  Fault
Bit 6  Warning
Bit 7  ImpIsActive
Bit 8  CInhIsActive
Bit 9  Fail CAN_Management
Bit 10  Reserved
Bit 11  Reserved
Bit 12  Reserved
Bit 13  Reserved
Bit 14  Lock bFail at TroubleQSP From version 11.00.00
1 ≡ The bFail output of the SB LS_DriveInterface
is also
set in the "TroubleQSP" status.
• Advantage: Even in the "TroubleQSP" status, an error
occurred before can still be recognised.
Bit 15  Use 16BitFailNo. From version 06.00.00
1 ≡ The short 16-bit error number
wStateDetermFailNoShort is provided at the
wStateDetermFailNoLow output of the
SB LS_DriveInterface
.
• In this case, the wStateDetermFailNoHigh output is
"0".
• Advantage: The bus transfer of the error numbers is
possible via a data word without changing the
interconnection of the technology application.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00148 | LS_DriveInterface: Error message config.
Data type: UNSIGNED_16
Index: 24427
d
= 5F6B
h
Parameter | Name:
C00150 | Status word
Data type: UNSIGNED_16
Index: 24425
d
= 5F69
h
Bit coded device status word
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 FreeStatus Free status bit 0
Bit 1 PowerDisabled Power switched off
Bit 2 FreeStatus Free status bit 2
Bit 3 FreeStatus Free status bit 3
Bit 4 FreeStatus Free status bit 4
Bit 5 FreeStatus Free status bit 5
Bit 6 ActSpeedIsZero Current speed is 0
Bit 7 ControllerInhibit Controller is inhibited
Bit 8 StatusCodeBit0 Status code bit 0
Bit 9 StatusCodeBit1 Status code bit 1
Bit 10 StatusCodeBit2 Status code bit 2
Bit 11 StatusCodeBit3 Status code bit 3
