15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00155
C00158
Bit 12 Warning Warning
Bit 13 Trouble Fault
Bit 14 FreeStatus Free status bit 14
Bit 15 FreeStatus Free status bit 15
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00150 | Status word
Data type: UNSIGNED_16
Index: 24425
d
= 5F69
h
Parameter | Name:
C00155 | Extended status word
Data type: UNSIGNED_16
Index: 24420
d
= 5F64
h
Bit coded device status word 2
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 Fail Error
Bit 1 M_max Maximum torque
Bit 2 I_max Maximum current
Bit 3 PowerDisabled Power switched off
Bit 4 Ready Controller is ready for operation
Bit 5 ControllerInhibit Controller is inhibited
Bit 6 Trouble Fault
Bit 7 InitState Initialisation
Bit 8 CwCcw CW/CCW rotation
Bit 9 TroubleQSP Quick stop due to fault is active
Bit 10 SafeTorqueOff Safe torque off
Bit 11 AplicationRunning Application is running
Bit 12 AplParSetBit0 Application parameter set - bit 0
Bit 13 AplParSetBit1 Application parameter set - bit 1
Bit 14 quick stop Quick stop active
Bit 15 Motor parameter identification Motor parameter identification is active
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00158 | Cause of controller inhibit
Data type: UNSIGNED_16
Index: 24417
d
= 5F61
h
Bit coded display of the cause/source of the controller inhibit
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
