Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 847
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00160
C00161
C00162
Parameter | Name:
C00160 | Status determining error (16bit)
Data type: UNSIGNED_16
Index: 24415
d
= 5F5F
h
From version 06.00.00
Display of the short 16-bit error number of the status determining error
Structure of the 16-bit error number (bit coding)
Display range (min. value | unit | max. value)
0 65535
Subcodes Info
C00160/1 Status determining error (16-bit)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00161 | LS_SetError_x: Error number
Data type: UNSIGNED_16
Index: 24414
d
= 5F5E
h
Setting of the error number for user error messages
Setting range (min. value | unit | max. value)
0 65535
Subcodes Lenze setting Info
C00161/1 1 LS_SetError_1
: Error no.1
C00161/2 2 LS_SetError_1
: Error no.2
C00161/3 3 LS_SetError_1
: Error no.3
C00161/4 4 LS_SetError_1
: Error no.4
C00161/5 1 LS_SetError_2
: Error no.1
C00161/6 2 LS_SetError_2
: Error no.2
C00161/7 3 LS_SetError_2
: Error no.3
C00161/8 4 LS_SetError_2
: Error no.4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00162 | Error number masked
Data type: UNSIGNED_32
Index: 24413
d
= 5F5D
h
From version 13.00.00
Display of the 32-bit error number of the status determining error without error type
• The error number displayed here only contains the error subject area and error ID (lower 26 bits of the 32-bit error
number)
Structure of the 32-bit error number (bit coding)
Display range (min. value | unit | max. value)
0 4294967295
Subcodes Info
C00162/1 Subject area + Id statuserror
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
