Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 853
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00168
C00169
C00170
C00171
Parameter | Name:
C00168 | Status determining error
Data type: UNSIGNED_32
Index: 24407
d
= 5F57
h
Display of the 32-bit error number of the status determining error
Structure of the 32-bit error number (bit coding)
Display range (min. value | unit | max. value)
0 4294967295
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00169 | Logbook setting
Data type: UNSIGNED_16
Index: 24406
d
= 5F56
h
Configuration which message types are to be logged in the logbook.
Setting range (min. hex value | max. hex value) Lenze setting
0x0000 0xFFFF 0x067E (decimal: 1662)
Value is bit-coded: ( =bit set)
Bit 0  Reserved
Bit 1  Log entry: Fault
Bit 2  Log entry: Trouble
Bit 3  Log entry: TroubleQuickstop
Bit 4  Log entry: WarningLocked
Bit 5  Log entry: Warning
Bit 6  Log entry: Information
Bit 7  Reserved
Bit 8  Reserved
Bit 9  Activation: Error counter
Bit 10  Activation: Log line refresh
Bit 11  Reserved
Bit 12  Reserved
Bit 13  Reserved
Bit 14  Reserved
Bit 15  Reserved
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00170 | Current error
Data type: UNSIGNED_32
Index: 24405
d
= 5F55
h
Display of the internal error number of the currently pending error
Display range (min. value | unit | max. value)
0 4294967295
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00171 | Logbook access index
Data type: UNSIGNED_8
Index: 24404
d
= 5F54
h
This code is for device-internal use only and must not be written to by the user!
