15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00342
Bit 11  Reserved
Bit 12  Reserved
Bit 13  Reserved
Bit 14  Reserved
Bit 15  Reserved
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00341 | CAN management - error configuration
Data type: UNSIGNED_16
Index: 24234
d
= 5EAA
h
Parameter | Name:
C00342 | CAN decoupling PDOInOut
Data type: UNSIGNED_16
Index: 24233
d
= 5EA9
h
From version 04.00.00
Configuration defining the events that lead to a decoupling of the process data words.
Configuring exception handling of the CAN PDOs
Setting range (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 BusOff_MsgErr
Bit 1 Warning
Bit 2 NodeStopped
Bit 3 HeartBeatEvent
Bit 4 CAN1_In_Überw.
Bit 5 CAN2_In_Überw.
Bit 6 CAN3_In_Überw.
Bit 7 CAN4_In_Überw. From version 15.00.00
Bit 8 Reserved
Bit 9 Reserved
Bit 10 Reserved
Bit 11 Reserved
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Trouble
Bit 15 Fault
Subcodes Lenze setting Info
C00342/1 0x0000 CAN decoupling PDO_In from the bus
C00342/2 0x0000 CAN decoupling PDO_Out from the appl.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
