15 Parameter reference
15.2 Parameter list
874
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00338
C00339
C00341
Parameter | Name:
C00338 | L_Arithmetik_1: Function
Data type: UNSIGNED_8
Index: 24237
d
= 5EAD
h
The L_Arithmetik_1 FB: Selection of internal arithmetics
Selection list (Lenze setting printed in bold)
0Out = In1
1 Out = In1 + In2
2 nOut_a = nIn1_a - nIn2_a
3 Out = (In1 * In2) / 100%
4 nOut_a = (nIn1_a * 1%) / |nIn2_a|
5 nOut_a = (nIn1_a * 100%) / (100% -
nIn2_a)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00339 | L_Arithmetik_2: Function
Data type: UNSIGNED_8
Index: 24236
d
= 5EAC
h
The L_Arithmetik_2 FB: Selection of internal arithmetics
Selection list (Lenze setting printed in bold)
0nOut_a = nIn1_a
1 nOut_a = nIn1_a + nIn2_a
2 nOut_a = nIn1_a - nIn2_a
3 nOut_a = (nIn1_a * nIn2_a) / 100%
4 nOut_a = (nIn1_a * 1%) / |nIn2_a|
5 nOut_a = (nIn1_a * 100%) / (100% -
nIn2_a)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00341 | CAN management - error configuration
Data type: UNSIGNED_16
Index: 24234
d
= 5EAA
h
From version 04.00.00
Selection of the events for which the bFail error output of the LS_CANMAnagement
SB must be set to TRUE.
Setting range (min. hex value | max. hex value) Lenze setting
0x0000 0xFFFF 0x0000 (decimal: 0)
Value is bit-coded: ( =bit set) Info
Bit 0  BusOff_MsgErr
Bit 1  Warning
Bit 2  NodeStopped
Bit 3  HeartBeatEvent
Bit 4  CAN1_In_Überw.
Bit 5  CAN2_In_Überw.
Bit 6  CAN3_In_Überw.
Bit 7  CAN4_In_Überw. From version 15.00.00
Bit 8  Reserved
Bit 9  Reserved
Bit 10  Reserved
