15 Parameter reference
15.2 Parameter list
882
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00359
C00360
C00358/1 8 CAN1_OUT data length
C00358/2 8 CAN2_OUT data length
C00358/3 8 CAN3_OUT data length
C00358/4 8 CAN4_OUT data length
• From version 15.00.00
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00358 | CANx_OUT data length
Data type: UNSIGNED_8
Index: 24217
d
= 5E99
h
Parameter | Name:
C00359 | CAN status
Data type: UNSIGNED_8
Index: 24216
d
= 5E98
h
"CAN on board" system bus
Selection list (read only)
0 Operational
1 Pre-Operat.
2 Reserved
3 Reserved
4 BootUp
5 Stopped
6 Reserved
7 Reset
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00360 | CAN telegram counter
Data type: UNSIGNED_16
Index: 24215
d
= 5E97
h
"CAN on board" system bus
Display range (min. value | unit | max. value)
0 65535
Subcodes Info
C00360/1 All PDO/SDO sent
C00360/2 All PDO/SDO received
C00360/3 Telegram counter CAN1_OUT
C00360/4 Telegram counter CAN2_OUT
C00360/5 Telegram counter CAN3_OUT
C00360/6 Telegram counter SDO1 OUT
C00360/7 Telegram counter SDO2 OUT
C00360/8 Telegram counter CAN1_IN
C00360/9 Telegram counter CAN2_IN
C00360/10 Telegram counter CAN3_IN
