Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 883
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00364
C00366
C00360/11 Telegram counter SDO1 IN
C00360/12 Telegram counter SDO2 IN
C00360/13 Telegram counter CAN4_OUT
• From version 15.00.00
C00360/14 Telegram counter CAN4_IN
• From version 15.00.00
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C00360 | CAN telegram counter
Data type: UNSIGNED_16
Index: 24215
d
= 5E97
h
Parameter | Name:
C00364 | CAN MessageError
Data type: UNSIGNED_8
Index: 24211
d
= 5E93
h
"CAN on board" system bus
Selection list (read only)
0 No Error
1 StuffError
2 FormError
3 AckError
4 Bit1Error
5 Bit0Error
6 CRCError
7 Reserved
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C00366 | Number of CAN SDO channels
Data type: UNSIGNED_8
Index: 24209
d
= 5E91
h
Functional change from version 05.01.00 onwards
Selection of the number of active parameter data channels
• Up to and including version 05.00.00, the parameter channels 1 and 2 are activated in the Lenze setting.
• From version 05.01.00 onwards, only the parameter data channel 1 is activated in the Lenze setting according to
CANopen. In order to activate both parameter data channels according to the previous behaviour, set
"2 SDO Lenze".
"CAN on board" system bus
Selection list (Lenze setting printed in bold)
01 SDO CANOpen
1 2 SDO Lenze
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
