15 Parameter reference
15.2 Parameter list
884
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00367
C00368
Parameter | Name:
C00367 | CAN SYNC Rx identifier
Data type: UNSIGNED_16
Index: 24208
d
= 5E90
h
Identifier by means of which the sync slave is to receive sync telegrams.
• Mapping of the CANopen object I-1005
(see DS301 V4.02).
"CAN on board" system bus
Setting range (min. hex value | max. hex value) Lenze setting
0x0000 0xFFFF 0x0080 (decimal: 128)
Value is bit-coded: ( =bit set)
Bit 0  COBID Bit0
Bit 1  COBID Bit1
Bit 2  COBID Bit2
Bit 3  COBID Bit3
Bit 4  COBID Bit4
Bit 5  COBID Bit5
Bit 6  COBID Bit6
Bit 7  COBID Bit7
Bit 8  COBID Bit8
Bit 9  COBID Bit9
Bit 10  COBID Bit10
Bit 11  Reserved
Bit 12  Reserved
Bit 13  Reserved
Bit 14  Reserved
Bit 15  Reserved
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00368 | CAN SYNC Tx identifier
Data type: UNSIGNED_16
Index: 24207
d
= 5E8F
h
Identifier by means of which the sync master is to transmit sync telegrams.
• Mapping of the CANopen object I-1005
(see DS301 V4.02).
"CAN on board" system bus
Setting range (min. hex value | max. hex value) Lenze setting
0x0000 0xFFFF 0x0080 (decimal: 128)
