Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 885
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00369
C00370
Value is bit-coded: ( =bit set)
Bit 0  COBID Bit0
Bit 1  COBID Bit1
Bit 2  COBID Bit2
Bit 3  COBID Bit3
Bit 4  COBID Bit4
Bit 5  COBID Bit5
Bit 6  COBID Bit6
Bit 7  COBID Bit7
Bit 8  COBID Bit8
Bit 9  COBID Bit9
Bit 10  COBID Bit10
Bit 11  Reserved
Bit 12  Reserved
Bit 13  Reserved
Bit 14  Reserved
Bit 15  Sync-transmit off
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00368 | CAN SYNC Tx identifier
Data type: UNSIGNED_16
Index: 24207
d
= 5E8F
h
Parameter | Name:
C00369 | CAN sync transmission cycle time
Data type: UNSIGNED_16
Index: 24206
d
= 5E8E
h
Cycle during which the sync master is to transmit sync telegrams.
• If "0 ms" is set (Lenze setting), no sync telegrams are generated.
• Mapping of the CANopen object I-1006
(see DS301 V4.02).
"CAN on board" system bus
Setting range (min. value | unit | max. value) Lenze setting
0 ms 65000 0ms
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00370 | SyncTxRxTimes
Data type: INTEGER_16
Index: 24205
d
= 5E8D
h
From version 04.00.00
"CAN on board" system bus
Display range (min. value | unit | max. value)
-1638 μs 1638
Subcodes Info
C00370/1 CAN Sync instant of transmission
C00370/2 Sync instant of reception
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
