Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 895
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00442
C00443
Value is bit-coded: ( =bit set)
Bit 0  SafeTorqueOff
Bit 1  ReadyToSwitchOn
Bit 2  SwitchedOn
Bit 3  Reserved
Bit 4  Trouble
Bit 5  Fault
Bit 6  Reserved
Bit 7  Reserved
Bit 8  Reserved
Bit 9  Fail CAN_Management
Bit 10  Reserved
Bit 11  Energy saving mode
Bit 12  Reserved
Bit 13  Reserved
Bit 14  Reserved
Bit 15  Reserved
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00441 | Decoupling AnalogOut
Data type: UNSIGNED_16
Index: 24134
d
= 5E46
h
Parameter | Name:
C00442 | AOutx: Decoupling value
Data type: INTEGER_16
Index: 24133
d
= 5E45
h
From version 04.00.00
Definition of the value the analog output terminals are to have in the decoupled state.
Configuring exception handling of the output terminals
Setting range (min. value | unit | max. value)
0.00 % 100.00
Subcodes Lenze setting Info
C00442/1 0.00 % AOut1_U: Decoupling value
C00442/2 0.00 % AOut2_U: Decoupling value
C00442/3 0.00 % AOut1_I: Decoupling value
C00442/4 0.00 % AOut2_I: Decoupling value
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00443 | DIx: Level
Data type: UNSIGNED_16
Index: 24132
d
= 5E44
h
Bit coded display of the level of the digital inputs
Digital input terminals
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
