Lenze 8400 - Page 897

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 897
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00445
C00446
Bit 0 Relay Bit set = HIGH level
Bit 1 DO1
Bit 2 DO2
Bit 3 DO3
Bit 4 High current
Bit 5 Reserved
Bit 6 Reserved
Bit 7 Reserved
Bit 8 Reserved
Bit 9 Reserved
Bit 10 Reserved
Bit 11 Reserved
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Reserved
Bit 15 Reserved
Subcodes Info
C00444/1 DOx: Input level
C00444/2 DOx: Terminal level
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00444 | DOx: Level
Data type: UNSIGNED_16
Index: 24131
d
= 5E43
h
Parameter | Name:
C00445 | FreqInxx_nOut_v
Data type: INTEGER_16
Index: 24130
d
= 5E42
h
From version 02.00.00
Display of the frequency input signals which are fed into the application.
Using DI1(6) and DI2(7) as frequency inputs
Display range (min. value | unit | max. value)
-32767 Incr/ms 32767
Subcodes Info
C00445/1 FreqIn12_nOut_v
C00445/2 FreqIn67_nOut_v
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00446 | FreqInxx_nOut_a
Data type: INTEGER_16
Index: 24129
d
= 5E41
h
From version 02.00.00
Display of the frequency input signals which are fed into the application.
Using DI1(6) and DI2(7) as frequency inputs
