15 Parameter reference
15.2 Parameter list
898
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00447
C00448
Display range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Info
C00446/1 FreqIn12_nOut_a
C00446/2 FreqIn67_nOut_a
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00446 | FreqInxx_nOut_a
Data type: INTEGER_16
Index: 24129
d
= 5E41
h
Parameter | Name:
C00447 | DigOut decoupling
Data type: UNSIGNED_16
Index: 24128
d
= 5E40
h
From version 04.00.00
Configuration defining the events that lead to a decoupling of the digital output terminals.
Configuring exception handling of the output terminals
Setting range (min. hex value | max. hex value) Lenze setting
0x0000 0xFFFF 0x0000 (decimal: 0)
Value is bit-coded: ( =bit set)
Bit 0  SafeTorqueOff
Bit 1  ReadyToSwitchOn
Bit 2  SwitchedOn
Bit 3  Reserved
Bit 4  Trouble
Bit 5  Fault
Bit 6  Reserved
Bit 7  Reserved
Bit 8  Reserved
Bit 9  Fail CAN_Management
Bit 10  Reserved
Bit 11  Energy saving mode
Bit 12  Reserved
Bit 13  Reserved
Bit 14  Reserved
Bit 15  Reserved
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00448 | DigOut decoupling value
Data type: UNSIGNED_16
Index: 24127
d
= 5E3F
h
From version 04.00.00
Definition of the value the digital output terminals are to have in the decoupled state.
• Bit set = HIGH level
Configuring exception handling of the output terminals
Setting range (min. hex value | max. hex value) Lenze setting
0x0000 0xFFFF 0x0000 (decimal: 0)
