15 Parameter reference
15.2 Parameter list
918
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00561
C00563
Selection list
0 Off
1 On
2 No fan
Subcodes Info
C00560/1 Switching status - internal fan
C00560/2 Switching status - heatsink fan
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00560 | Fan switching status
Data type: UNSIGNED_8
Index: 24015
d
= 5DCF
h
Parameter | Name:
C00561 | Failure indication
Data type: UNSIGNED_8
Index: 24014
d
= 5DCE
h
Failure display of device fans and motor phases
Selection list
0 No error
1 Error
Subcodes Info
C00561/1 Internal fan
C00561/2 Heatsink fan
C00561/3 Motor phase U
• From version 11.00.00
C00561/4 Motor phase V
• From version 11.00.00
C00561/5 Motor phase W
• From version 11.00.00
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00563 | Current monitoring: Delay time
Data type: UNSIGNED_32
Index: 24012
d
= 5DCC
h
From version 16.00.00
Current monitoring overload
Setting range (min. value | unit | max. value)
0.000 s 999.900
Subcodes Lenze setting Info
C00563/1 3.000 s Current monitoring: Delay time overload
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
