15 Parameter reference
15.2 Parameter list
920
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00570
C00571
C00572
Parameter | Name:
C00570 | Resp. to controller limitations
Data type: UNSIGNED_8
Index: 24005
d
= 5DC5
h
Configuration of monitoring of the motor control (group 2)
Selection list
0 No Reaction
1Fault
5 Warning
Subcodes Lenze setting Info
C00570/1 0: No Reaction Response if direct-axis current controller is limited
• e.g. at servo control (SC
)
C00570/2 0: No Reaction Response if cross current controller is limited
• e.g. at servo control (SC
)
C00570/3 0: No Reaction Response if torque setpoint is limited
• Limitation of the speed controller output, the
differential setpoint precontrol, and of the additive
torque at (SC
) servo control and (SLVC) sensorless
vector control.
C00570/4 0: No Reaction Response if field controller is limited
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00571 | Resp. to wrong controller setting
Data type: UNSIGNED_8
Index: 24004
d
= 5DC4
h
From version 14.00.00
Selection list
0 No Reaction
1Fault
2Trouble
3 TroubleQuickStop
4 WarningLocked
5 Warning
6 Information
Subcodes Lenze setting Info
C00571/1 6: Information Resp. to: Motor control does not match motor data
C00571/2 1: Fault Resp. to a non-set speed controller
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00572 | Brake resistor overload threshold
Data type: UNSIGNED_8
Index: 24003
d
= 5DC3
h
From version 02.00.00
Adjustable threshold for monitoring the brake resistor utilisation
• The response for reaching the threshold can be selected in C00574
.
Setting range (min. value | unit | max. value) Lenze setting
0 % 100 100 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
