Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 923
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00582
C00584
C00585
C00586
Parameter | Name:
C00582 | Resp. to heatsink temp. > shutdown temp. -5°C
Data type: UNSIGNED_8
Index: 23993
d
= 5DB9
h
Response if the heatsink temperature has reached the switch-off temperature threshold.
Selection list (Lenze setting printed in bold)
0No Reaction
1Fault
5 Warning
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00584 | Resp. to current monitoring
Data type: UNSIGNED_8
Index: 23991
d
= 5DB7
h
From version 16.00.00
Response in the event of current overload
Current monitoring overload
Selection list Info
0 No Reaction
1Fault
3 TroubleQuickStop
4 WarningLocked
5 Warning
6 Information
Subcodes Lenze setting Info
C00584/1 0: No Reaction Resp. to current monitoring overload
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00585 | Resp. to motor overtemp. PTC
Data type: UNSIGNED_8
Index: 23990
d
= 5DB6
h
Response to motor overtemperature
• The motor temperature is measured by means of a PTC thermistor at terminal X106.
Selection list (Lenze setting printed in bold)
0 No Reaction
1Fault
5 Warning
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00586 | Resp. to open circuit HTL encoder
Data type: UNSIGNED_8
Index: 23989
d
= 5DB5
h
Response to encoder feedback system failure or encoder feedback system track failure due to open circuit
Selection list (Lenze setting printed in bold)
0 No Reaction
1Fault
5 Warning
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
