Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 941
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00622
C00621/196 0: Not connected LP_CanOut4
: bOut1_B12
C00621/197 0: Not connected LP_CanOut4
: bOut1_B13
C00621/198 0: Not connected LP_CanOut4
: bOut1_B14
C00621/199 0: Not connected LP_CanOut4
: bOut1_B15
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00621 | System connection list: Bool
Data type: UNSIGNED_16
Index: 23954
d
= 5D92
h
Parameter | Name:
C00622 | System connection list: Angle
Data type: UNSIGNED_16
Index: 23953
d
= 5D91
h
Connection parameters: 32-bit inputs
• Selection of the 32-bit output signals for connection with the 32-bit input signals.
• The selection list contains all 32-bit output signals which can be assigned to the 32-bit inputs mapped by the
subcodes.
• Non-listed subcodes are "reserved".
Selection list
See selection list - angle signals
Subcodes Lenze setting Info
C00622/1 0: Not connected LS_DisFree_p
: dnDis1_p
Display of 32-bit signal 1
C00622/2 0: Not connected LS_DisFree_p
: dnDis2_p
Display of 32-bit signal 2
C00622/3 0: Not connected LS_DisFree_p
: dnDis3_p
Display of 32-bit signal 3
C00622/4 0: Not connected LS_DisFree_p
: dnDis4_p
Display of 32-bit signal 4
C00622/5 0: Not connected LS_DisFree_p
: dnDis5_p
Display of 32-bit signal 5
C00622/6 0: Not connected LS_DisFree_p
: dnDis6_p
Display of 32-bit signal 6
C00622/7 0: Not connected LS_DisFree_p
: dnDis7_p
Display of 32-bit signal 7
C00622/8 0: Not connected LS_DisFree_p
: dnDis8_p
Display of 32-bit signal 8
C00622/9 0: Not connected LP_CanOut1
: dnOut34_p
CAN1 output: Data words 3 + 4
C00622/10 0: Not connected LP_CanOut2
: dnOut34_p
CAN2 output: Data words 3 + 4
C00622/11 0: Not connected LP_CanOut3
: dnOut34_p
CAN3 output: Data words 3 + 4
C00622/12 0: Not connected LP_MciOut
: dnOut34_p
MCI output: Data words 3 + 4
C00622/13 0: Not connected LS_DigitalInput
: dnPosIn12_Set_p
Frequency input DI1/DI2: Starting value for angle
integrator
C00622/16 0: Not connected LS_RetainData
: dnIn1
Retain data: 32-bit input value 1
C00622/17 0: Not connected LS_RetainData
: dnIn2
Retain data: 32-bit input value 2
C00622/18 0: Not connected LS_RetainData
: dnIn3
Retain data: 32-bit input value 3
