15 Parameter reference
15.2 Parameter list
942
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00630
C00631
C00632
C00622/19 0: Not connected LS_RetainData
: dnIn4
Retain data: 32-bit input value 4
C00622/25 0: Not connected LP_CanOut4
: dnOut34_p
CAN4 output: Data words 3 + 4
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C00622 | System connection list: Angle
Data type: UNSIGNED_16
Index: 23953
d
= 5D91
h
Parameter | Name:
C00630 | L_Limit 1-2: Min/Max
Data type: INTEGER_16
Index: 23945
d
= 5D89
h
Setting the limits
Setting range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Lenze setting Info
C00630/1 -199.99 % L_Limit_1
: Min.Limit
C00630/2 199.99 % L_Limit_1
: Max.Limit
C00630/3 -199.99 % L_Limit_2
: Min.Limit
C00630/4 199.99 % L_Limit_2
: Max.Limit
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00631 | L_LimitPhi 1-3: Min/Max
Data type: INTEGER_32
Index: 23944
d
= 5D88
h
Setting the limits
Setting range (min. value | unit | max. value)
-2147483647 Incr. 2147483647
Subcodes Lenze setting Info
C00631/1 -2147483647 incr. L_LimitPhi_1
: Min.Limit
C00631/2 2147483647 incr. L_LimitPhi_1: Max.Limit
C00631/3 -2147483647 incr. L_LimitPhi_2
: Min.Limit
C00631/4 2147483647 incr. L_LimitPhi_2
: Max.Limit
C00631/5 -2147483647 incr. L_LimitPhi_3: Min.Limit
C00631/6 2147483647 incr. L_LimitPhi_3
: Max.Limit
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C00632 | L_NSet_1: Max.SkipFrq.
Data type: INTEGER_16
Index: 23943
d
= 5D87
h
Maximum limit values for the speed blocking zones
Selection of the maximum limit values for the blocking zones in which the speed must not be constant.
Setting range (min. value | unit | max. value)
0.00 % 199.99
