Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 943
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00633
C00634
Subcodes Lenze setting Info
C00632/1 0.00 % L_NSet_1
: Blocking speed1 max
C00632/2 0.00 % L_NSet_1
: Blocking speed2 max
C00632/3 0.00 % L_NSet_1
: Blocking speed3 max
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00632 | L_NSet_1: Max.SkipFrq.
Data type: INTEGER_16
Index: 23943
d
= 5D87
h
Parameter | Name:
C00633 | L_NSet_1: Min.SkipFrq.
Data type: INTEGER_16
Index: 23942
d
= 5D86
h
Minimum limit values for the speed blocking zones
• Selection of the minimum limit values for the blocking zones in which the speed must not be constant.
Setting range (min. value | unit | max. value)
0.00 % 199.99
Subcodes Lenze setting Info
C00633/1 0.00 % L_NSet_1
: Blocking speed1 min
C00633/2 0.00 % L_NSet_1
: Blocking speed2 min
C00633/3 0.00 % L_NSet_1
: Blocking speed3 min
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00634 | L_NSet_1: wState
Data type: UNSIGNED_16
Index: 23941
d
= 5D85
h
The L_NSet_1 FB: Bit coded status display
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 No blocking zone active 1 ≡ No blocking zone set for constant speeds
Bit 1 Blocking zone 1 active 1 ≡ Suppression of constant speed characteristics within
the limits of blocking zone 1
Bit 2 Blocking zone 2 active 1 ≡ Suppression of constant speed characteristics within
the limits of blocking zone 2
Bit 3 Blocking zone 3 active 1 ≡ Suppression of constant speed characteristics within
the limits of blocking zone 3
Bit 4 Jog in blocking zone 1 ≡ A ramp is used to keep the speed setpoint within a
speed blocking zone
Bit 5 MaxLimit active 1 ≡ Speed setpoint is at the maximum speed limit
Bit 6 MinLimit active 1 ≡ Speed setpoint is at the minimum speed limit
Bit 7 Reserved
Bit 8 Reserved
Bit 9 Reserved
Bit 10 Reserved
Bit 11 Reserved
