Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 963
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00725
C00726
C00727
Parameter | Name:
C00725 | Current switching frequency
Data type: UNSIGNED_8
Index: 23850
d
= 5D2A
h
Display of the current switching frequency
•In C00018
you can choose between a drive-optimised setting for good smooth-running characteristics and an
inverter loss-optimised setting (min. Pv).
• Both possibilities offer fixed and variable switching frequencies.
• When a variable switching frequency is selected in C00018
, the switching frequency may change as a function
of the load and rotational frequency.
Selection list (read only)
1 4 kHz var./drive-optimised
2 8 kHz var./drive-optimised
3 16 kHz var./drive-optimised
5 2 kHz constant/drive-optimised
6 4 kHz constant/drive-optimised
7 8 kHz constant/drive-optimised
8 16 kHz constant/drive-optimised
11 4 kHz var./min. Pv
12 8 kHz var./min. Pv
13 16 kHz var./min. Pv
14 Reserved
15 2 kHz constant/min. Pv
16 4 kHz constant/min. Pv
17 8 kHz constant/min. Pv
18 16 kHz constant/min. Pv
21 8 kHz var./drive-opt./4 kHz min
22 16 kHz var./drive-opt./4 kHz min
23 16 kHz var./drive-opt./8 kHz min
31 8 kHz var./min. Pv/4 kHz min
32 16 kHz var./min. Pv/4 kHz min
33 16 kHz var./min. Pv/8 kHz min
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00726 | Current limit values
Data type: UNSIGNED_8
Index: 23849
d
= 5D29
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00727 | LS_Keypad digital values
Data type: UNSIGNED_8
Index: 23848
d
= 5D28
h
Execution of control commands for keypad operation
Setting range (min. value | unit | max. value)
01
Subcodes Lenze setting Info
C00727/1 0 1 ≡ request quick stop
C00727/2 0 1 ≡ request DC-injection braking
