Lenze 8400 - Page 980

15 Parameter reference
15.2 Parameter list
980
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00830
C00829/21 0: FALSE L_DigitalLogic_3
: bOut3: bIn3...bIn1=1 0 0
C00829/22 0: FALSE L_DigitalLogic_3
: bOut3: bIn3...bIn1=1 0 1
C00829/23 0: FALSE L_DigitalLogic_3
: bOut3: bIn3...bIn1=1 1 0
C00829/24 0: FALSE L_DigitalLogic_3
: bOut3: bIn3...bIn1=1 1 1
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00829 | L_DigitalLogic_3: Truth table
Data type: UNSIGNED_8
Index: 23746
d
= 5CC2
h
Parameter | Name:
C00830 | 16-bit inputs [%]
Data type: INTEGER_16
Index: 23745
d
= 5CC1
h
Display in percent of 16-bit input values of different blocks
• Non-listed subcodes are "reserved".
Display range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Info
C00830/1 L_Absolut_1
: nIn_a
C00830/2 L_AddSub_1
: nIn1_a
C00830/3 L_AddSub_1
: nIn2_a
C00830/4 L_AddSub_1
: nIn3_a
C00830/5 L_OffsetGain_1
: nIn_a
C00830/6 L_OffsetGain_1
: nOffset_a
C00830/7 L_OffsetGain_1
: nGain_a
C00830/8 L_Negation_1
: nIn_a
C00830/9 L_GainOffset_1
: nIn_a
C00830/10 L_GainOffset_1
: nGain_a
C00830/11 L_GainOffset_1
: nOffset_a
C00830/12 L_Arithmetik_1: nIn1_a
C00830/13 L_Arithmetik_1
: nIn2_a
C00830/14 L_AnalogSwitch_1: nIn1_a
C00830/15 L_AnalogSwitch_1
: nIn2_a
C00830/16 L_Compare_1
: nIn1_a
C00830/17 L_Compare_1: nIn2_a
C00830/18 MCTRL
: nTorqueLimitAdapt_a
C00830/20 MCTRL
: nPosCtrlPAdapt_a
C00830/21 MCTRL
: nPosCtrlOutLimit_a
C00830/22 MCTRL
: nSpeedSetValue_a
C00830/23 MCTRL
: nSpeedLowLimit_a
C00830/24 MCTRL
: nSpeedCtrlI_a
C00830/25 MCTRL
: nSpeedCtrlPAdapt_a
C00830/26 MCTRL
: nBoost_a
C00830/27 MCTRL
: nTorqueSetValue_a
C00830/28 MCTRL
: nTorqueGenLimit_a
C00830/29 MCTRL
: nTorqueMotLimit_a
C00830/31 MCTRL
: nVoltageAdd_a
C00830/32 MCTRL
: nPWMAngleOffset_a
