Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 979
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00828
C00829
Parameter | Name:
C00828 | L_DigitalLogic_3: Function
Data type: UNSIGNED_8
Index: 23747
d
= 5CC3
h
From version 11.00.00
The L_DigitalLogic_3
FB: Selection of the internal logic function
Selection list (Lenze setting printed in bold) Info
0bOut = 0 Constant value "FALSE"
1 bOut = 1 Constant value "TRUE"
2 bOut = bIn1 AND bIn2 AND bIn3 AND operation
3 bOut = bIn1 OR bIn2 OR bIn3 OR operation
4 bOut = f (truth table) The truth table parameterised in C00829
is used.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00829 | L_DigitalLogic_3: Truth table
Data type: UNSIGNED_8
Index: 23746
d
= 5CC2
h
From version 11.00.00
The L_DigitalLogic_3
FB: Parameterisation of the truth table
Selection list
0False
1True
Subcodes Lenze setting Info
C00829/1 0: FALSE L_DigitalLogic_3
: bOut: bIn3...bIn1=0 0 0
C00829/2 0: FALSE L_DigitalLogic_3
: bOut: bIn3...bIn1=0 0 1
C00829/3 0: FALSE L_DigitalLogic_3
: bOut: bIn3...bIn1=0 1 0
C00829/4 0: FALSE L_DigitalLogic_3
: bOut: bIn3...bIn1=0 1 1
C00829/5 0: FALSE L_DigitalLogic_3
: bOut: bIn3...bIn1=1 0 0
C00829/6 0: FALSE L_DigitalLogic_3: bOut: bIn3...bIn1=1 0 1
C00829/7 0: FALSE L_DigitalLogic_3
: bOut: bIn3...bIn1=1 1 0
C00829/8 0: FALSE L_DigitalLogic_3
: bOut: bIn3...bIn1=1 1 1
C00829/9 0: FALSE L_DigitalLogic_3: bOut2: bIn3...bIn1=0 0 0
C00829/10 0: FALSE L_DigitalLogic_3
: bOut2: bIn3...bIn1=0 0 1
C00829/11 0: FALSE L_DigitalLogic_3
: bOut2: bIn3...bIn1=0 1 0
C00829/12 0: FALSE L_DigitalLogic_3: bOut2: bIn3...bIn1=0 1 1
C00829/13 0: FALSE L_DigitalLogic_3
: bOut2: bIn3...bIn1=1 0 0
C00829/14 0: FALSE L_DigitalLogic_3
: bOut2: bIn3...bIn1=1 0 1
C00829/15 0: FALSE L_DigitalLogic_3
: bOut2: bIn3...bIn1=1 1 0
C00829/16 0: FALSE L_DigitalLogic_3
: bOut2: bIn3...bIn1=1 1 1
C00829/17 0: FALSE L_DigitalLogic_3
: bOut3: bIn3...bIn1=0 0 0
C00829/18 0: FALSE L_DigitalLogic_3
: bOut3: bIn3...bIn1=0 0 1
C00829/19 0: FALSE L_DigitalLogic_3
: bOut3: bIn3...bIn1=0 1 0
C00829/20 0: FALSE L_DigitalLogic_3
: bOut3: bIn3...bIn1=0 1 1
